Features & Rigging Componentry
432cc Two-Cylinder High Thrust
Optional Multi-Function Tiller
With the latest technologies, ergonomic design and features, Yamaha's Multi-Function Tiller Handle delivers effortless control, maneuverability and comfort. Trim, shift, throttle, stop switch, variable trolling and integrated overheating and low oil pressure warning alerts are also built into the handle.
Variable Trolling Control
Yamaha’s variable trolling control allows you to precisely adjust the engine’s idling speed from 750 to 1050 RPM, in 50 RPM increments. The ability to finely tune the trolling speed allows fisherman to perfect their lure presentation when chasing different species of fish.
Dual Thrust Propeller
Yamaha's large-diameter, low-pitch dual-thrust propellers are designed to give instant power in both forward and reverse, by redirecting exhaust gases way from the propeller, reducing reverse ventilation and generating more power to the water. This design increases forward thrust by up to 60% and reverse thrust by up to 70%.
Electronic Fuel Injection
The Multi-Point Electronic Fuel Injection (EFI) system, in conjunction with the Engine Control Module (ECM), injects the right amount of fuel into the combustion chamber at the optimum timing. This results in ‘first-time, every-time’ hot and cold starting, improved fuel efficiency and excellent throttle response.
Fresh Water Flushing System
Large Diameter Propeller
Mechanical Steering Control
Power Trim and Tilt
Yamaha’s push-button trim control makes engine trim and tilt adjustments quick, smooth and easy, across a wide trim range. The negative trim settings allow for improved acceleration and the ability to bring the boat onto the plane more quickly.
Anti-Corrosion - 5 Stage Paint System
Exclusive to Yamaha, Prime Start makes starting your outboard as easy as starting a car. It allows the engine to be started cold by automatically controlling the engine ‘warming up’ process - eliminating the need for a conventional choke. This means you no longer need to ‘warm up’ your engine by revving it in neutral.
703 Side-Mounted Control
One of Yamaha's best selling controls, this mechanical remote offers comfort, simplicity and flexibility. With its new ergonomic grip, reversible right-hand or left-hand installation, and convenient trim and tilt operation, this control offers all-round functionality and value.
6x3 Concealed Side-Mounted Control
With its stylish chrome finish and ergonomic design, this mechanical control not only looks good, but provides effortless one-hand operation. The trim and tilt switch is comfortably located on the handle and features easily accessible neutral warm-up controls and externally adjustable throttle friction.
704 Premium Single Binnacle Control
This highly-polished, stylish looking, top mounted control allows for effortless one-handed control. The ergonomic design features a thumb operated trim and tilt switch built into the handle, as well as shift and throttle control functions, for convenient and comfortable operation.
Genuine Yamaha Propellers
Prop choice makes a huge difference to outboard acceleration, top-end speed, handling and fuel efficiency. That is why Yamaha continues to push the technological boundaries in the design and development of our leading range of high performance props - ensuring every Yamaha outboard performs at its peak.
Alloy White Dual Thrust Series
Designed for sailboats and other large displacement craft, Yamaha’s dual thrust props are built to push heavy loads through the water. The hub is carefully designed to redirect exhaust flow away from the blades, cutting through clean water for higher efficiency and better acceleration.
- Engine Type 4-Stroke, SOHC In-line 2
- Bore x Stroke (mm) 65 x 65.1
- Fuel Tank Capacity (l)
- Displacement (cc) 432.0
- Recommended Maximum RPM 5000-6000
- Fuel Management Regular Unleaded
- Ignition CDI
- OEDA Emission Rating 3
- Lubrication System Wet-sump
- Alternator Output 16A
- Gear Ratio 2.08 : 1
- Starter System Electric Start with Manual Backup
- Operation Method Mechanical control (Tiller Optional)
- Trim and Tilt Method Power Trim & Tilt
- Digital Gauges Optional
- Command Link Gauges Optional
- Transom Height (mm [inch]) L: 551 [21.7] | X: 625 [24.6]
- Dry Weight (kg) L: 64 | X: 70
